Features • Manual on/off DC remote control kit • Easy-to-read backlit LCD screen • Displays room temperature • Pre-installed 400º high temp wires • Built-in overheating protection switch • Self-matching receiver and transmitter • Childproof switch • Easy-to-access battery drawer Know the exact temperature of any room instantly with the Acumen Remote Control Kit. This is a manual on/off DC remote kit that displays the room temperature with an easy to read backlit LCD screen. It comes with a built in overheating protection switch, and even has a childproof switch for those homeowners with young ones. Changing batteries is simple and fast with the easy to access battery drawer and the Acumen Remote Control Kit also has a self-matching receiver and transmitter. I have an Acumen Model FDC-504 transmitter and a Rx05 receiver.
The receiver on/off switch only works when the manual fireplace rocker is switched to off. Should the receiver off/on switch turn the fireplace off/on, while the manual fireplace rocker is switched to on? I can not get a beep when pairing these up, according to the directions they should.
Acumen RCK-IS Manual On/Off DC Remote Control Kit. Is there somewhere from I can download the user manual? I have an Acumen model FDC-504 remote control kit.
The receiver leads are wired correctly and the batteries are fresh. The red light is not lit up on the receiver. Download The Broadview Anthology Of Expository Prose Ebook3000. Should the red light on the receiver be lit up if the batteries are good? What is the minimum DC voltage on the wiring leads from the receiver? Normally, the rocker switch within the fireplace will indeed be in the 'on' position when wiring in a remote receiver.
The receiver would then slide between 'off' and 'on' to manually control the unit. The battery light on the RX05 receiver should only be lit when there is a low battery condition. The receiver works like an inline switch and should not provide any voltage to the gas valve within the fireplace. The receiver should only allow the millivoltage generated by the standing pilot to pass through the receiver and back to the control valve. I purchased our home and it had an Acumen Model FDC-502.
S/N 156271 that worked fine through the winter. The following fall we put fresh batteries in the receiver and remote and it stopped working correctly.
The code switches are all in the off position and the CP is not on. I am not sure if it is paired with the receiver or if one or the other is not working.
I do not get a beep from the receiver in trying to pair but I'm not sure if it even does that on this model. With out a manual not sure. How do I troubleshoot this?
The receiver for this model does indeed beep when paired. If it does not, the system may be defective and require replacement. The pairing procedure is as follows. Remove the batteries from the remote and the receiver. Ensure the code switches match on both devices. Install batteries in the receiver only.
Switch the receiver off. Install batteries in the remote. Switch the receiver to the remote position. Push any button on the remote. When a button on the remote is pushed, the set should again be paired and a beep should be emitted from the receiver. If not, the set is likely defective.
The remote kit you are viewing now is a suitable replacement. I'm having difficulty installing an Acumen RCK-I model J remote control. I plugged the receiver into the TH and TH/TP terminals, installed the batteries in both the receiver and the remote, and heard the beep indicating that the transmitter and receiver had successfully paired. In general, I would say that the remote does not operate properly, but in certain circumstances it will turn the fire on and off.
I'm still trying to completely understand what these circumstances are, but they appear to be related to whether or not I have attempted to use the remote while the fire was activated via the manual on/off switch which shares the TH and TH/TP terminals. Specifically, if I turn the fire on manually via the on/off switch, and then try to turn it off with the remote, nothing will happen, But if I then turn the fire off manually, the remote will operate properly for at least a short time. The wiring may be difficult to see, but I have enclosed an image below.
